Quanta Light 4V Evo Series multi-wavelength laser system
$5,000.00
Description
The Quanta Light 4V Evo Series is a multi-wavelength laser system manufactured by Quanta System for aesthetic and dermatologic applications. The \”4V\” designation refers to its ability to incorporate up to four laser wavelengths, with additional optional handpieces for expanded functionality. The \”5\” likely indicates a configuration that includes a fifth laser source or handpiece, often a KTP 532nm laser, Twain IPL, or an Er:YAG 2940nm.
The \”2020\” in the product name indicates a model year, though the core specifications are consistent within the Light Evo platform released around that time.
Laser sources and wavelengths
The system can be configured with a combination of the following laser types:
- 755 nm (Alexandrite): Best for treating hair removal in skin types I–IV and removing benign pigmented lesions.
- 1064 nm (Nd:YAG): Suitable for hair removal on all skin types, deep and shallow vascular lesions, and skin rejuvenation.
- 532 nm (KTP, or a frequency-doubled Nd:YAG): Highly effective for targeting superficial pigmented and vascular lesions.
- 1320 nm (Optional Nd:YAG): Used for non-ablative skin rejuvenation and treating wrinkles and acne scars.
Optional handpieces
The system\’s modular \”Twain\” connector allows for additional handpieces, expanding treatment options further:
- Twain IPL: An optional Intense Pulsed Light (IPL) handpiece that treats a broader range of skin indications, including photorejuvenation.
- Twain 2940 nm (Er:YAG): An optional Erbium YAG laser handpiece for ablative and fractional skin resurfacing.
Key features
- Elluminate treatment: A proprietary technique that uses multiple wavelengths (532nm, 755nm, 1064nm, and 2940nm) in a single session to create a synergistic effect, improving overall skin tone, texture, and radiance.
- Versatility: The ability to combine multiple laser wavelengths in a single platform allows for treating a wide array of dermatological and aesthetic concerns, reducing the need for multiple devices.
- Customization: The system offers adjustable spot sizes (e.g., 2–16 mm), pulse widths, and repetition rates for precise and customized treatments.
- Integrated cooling: Built-in skin cooling, either integrated contact cooling or an air cooling adapter, helps ensure patient comfort and safety.
- User interface: A 10.4-inch touchscreen display with an intuitive graphical interface simplifies operation.
- OptiBeam II technology: Provides a homogeneous beam profile and large spot sizes, which ensures uniform and efficient energy distribution.
- Reliability: The system is designed with hardware and software for quick start-up and is built to handle intensive use in a clinical setting.
Specifications
- Laser Classification: Class 4.
- Weight: 150 kg.
- Dimensions: 530 (W) x 1043 (D) x 1060 (H) mm.
- Power: 200–240 Vac; 50/60 Hz; 3.7 kVA.
- Cooling System: Closed water circuit with a water-air exchanger.
